Nylon Sunglasses Lens Gradient Green Tinted
Engineered Optical Excellence
Every lens inherits five core performance pillars — from optical purity to impact safety.
Supreme Optical Clarity
Engineered exclusively as 0.00D Plano Lenses with an Abbe Value of 52, rivaling crown glass for ultimate optical purity. Low internal stress design guarantees minimal optical distortion and zero edge color fringing.
Seamless Dual-Zone VLT
High-Temp Precision Dip-Dyeing achieves a flawless transition from Top CAT 3 (8-18% VLT) for glare blocking to Bottom CAT 2 (18-43% VLT) for near-field clarity. Strictly controlled batch symmetry with Delta E < 1.0 and zero visible color banding.
Ultra-Lightweight & Crack Resistant
Specific Gravity of 1.01 for a truly weightless wearing experience. Delivers exceptional mechanical stability, absolutely immune to edge chipping during CNC drilling and slotting for rimless designs.
UV400 Full Protection
Offers uncompromised 100% blockage of UVA and UVB rays (≤400nm, ≥99% blocking) consistently across both the dark and light transition zones.
Precision Alignment Marks
To solve the industry pain point of tilted gradient lines during CNC edging, all gradient blanks feature high-precision, washable eco-ink horizontal axis lines. This completely eliminates alignment defects and maximizes your rimless assembly yield rate.
Nylon Sunglasses Lens Gradient Color Green Tinted
Click to play and see the optical performance and real-world clarity of our green gradient nylon sunglass lenses — showcasing the seamless CAT 3-to-CAT 2 tint transition.
Technical Specifications
| Material | Optical Grade Nylon (Polyamide) |
| Color | Couture Gradient Green (Pantone matching available) |
| VLT / Category | CAT 3: 8-18% (Top / Dark Zone) / CAT 2: 18-43% (Bottom / Light Zone) |
| UV Protection | UV400 (≤400nm, ≥99% blocking) |
| Abbe Value | 52 |
| Specific Gravity | 1.01 g/cm³ |
| Optical Accuracy | Plano 0.00D; Residual Astigmatism ≤0.09D; Residual Prism ≤0.12Δ, measured at the optical reference point. |
| Base Curve | 2C / 4C / 6C / 8C Available |
| Center Thickness | 1.5mm - 2.0mm (±0.05mm) |
| Diameter | 71mm / 75mm / 80mm (custom available) |
| Impact Test | FDA 21 CFR 801.410 Pass |
| Certifications | CE / FDA / UKCA / GB / ANSI / EN / AS/NZS |
| MOQ | 300 Pairs/Specification |
| Origin | Shenzhen, China |
| Logo | Laser engraving (recommended for gradient lenses), Screen printing, UV printing, Decal, Embedded logo |
Production-Ready Integration
Everything you need to source with confidence
- Acetate Frames — Highly recommended. Excellent chemical resistance against acetate plasticizers. Completely immune to stress cracking caused by Acetate's cooling shrinkage during fitting.
- Rimless / Drill-mount — Supreme tensile strength ensures zero edge chipping during CNC drilling and slotting.
- Titanium / Carbon Fiber / Metal / TR90 Frames — Optimal compatibility, lightweight and corrosion-resistant, ideal for premium eyewear frame designs.
- Pantone matching for precise gradient base colors and bi-color transitions (e.g., Sunset Gradient)
- Custom gradient zone ratio — dark zone depth adjustable (e.g., top 40% / bottom 60% of lens height)
- B-AR (Back-Surface AR) coating recommended to eliminate rear reflections
- Coating upgrades: HC / Oleophobic / Hydrophobic / Anti-fog
- Simple Packaging: PE bag + white box, Premium Packaging: Individual color box + cloth bag, Blister: Transparent blister box, Custom: Brand LOGO packaging
- MOQ: 300 Pairs/Specification
- Sample Lead Time: 7–10 working days, allowing you to verify gradient quality before bulk order
- Bulk Lead Time: 15–20 working days (subject to quantity and customization complexity)
- Custom Options: Pantone color matching, custom VLT zone ratio, dark-zone depth control, bi-color gradient transitions, B-AR coating, OEM/ODM laser logo, custom packaging
- Reports: Light Transmittance Test Report, UV Blocking Test Report, Impact Resistance Test Report, Color Consistency (Delta E) Test Report, Salt Spray Test Report
Features & Applications
Technical Features
- Optical Purity: An Abbe Value of 52 rivals crown glass for clarity. This optical grade nylon virtually eliminates the visual distortion that typically drives customer complaints.
- Seamless Gradient Transition: High-temp precision dip-dyeing achieves a flawless fade from CAT 3 sun protection down to CAT 2 near-field clarity. This zero-banding precision helps Independent Eyewear Designers launch sophisticated collections without manufacturing defects.
- Regulatory Compliance: We guarantee 100% blockage of UVA and UVB rays (≤400nm) consistently across both the dark and light transition zones. Full adherence to CE, FDA, and ANSI standards keeps your business completely safe from export delays.
- Scrap Reduction: The ultra-low specific gravity of 1.01 g/cm³ delivers exceptional mechanical stability. Supreme tensile strength completely prevents edge-chipping during CNC drilling and slotting, which heavily reduces material waste during assembly.
- Mechanical Safety: Post-sale warranty claims are drastically minimized. These lenses fully pass the FDA 21 CFR 801.410 drop-ball test, providing reliable shatter resistance for Premium Eyewear Brands.
- Scalable Manufacturing: Prototype new gradient lines with minimal financial risk. Tailored base curves (2C-8C), custom diameters up to 80mm, and precise Pantone color matching are available starting at a highly accessible 300-pair MOQ.
Perfect For
- Premium Eyewear Brands
- Independent Eyewear Designers
- Private Label Distributors
- High-End Optical Chains
- Concept & Multi-Brand Stores
- Luxury Fashion Houses
Dual-Zone VLT Reference
| Gradient Zone | VLT (%) | Category | Usage Environment |
|---|---|---|---|
| Top (Dark Zone) | 8% - 18% | CAT 3 | Direct sunlight, outdoor glare blocking |
| Bottom (Light Zone) | 18% - 43% | CAT 2 | Near-field clarity, reading, driving view |
Note: The gradient transition is continuous with zero visible banding. Delta E < 1.0 batch-to-batch consistency is enforced at the factory level.
Overview
Fashion-driven retail collections require a gradient lens that balances sophisticated aesthetic appeal with functional dual-zone clarity. The subtle green fade delivers a signature look for modern eyewear lines while maintaining comfortable near-field vision.
Strict dip-dyeing chemistry holds the color transition steady across every batch, ensuring your production line runs without costly visual inconsistencies. You can specify precise color targets and transition ratios for your collection, as Xinxin builds the entire customization flow under one roof.
Precision Dip-Dye Manufacturing — How Xinxin Crafts Gradient Nylon Sunglass Lenses in Shenzhen
Click to play and see how our green gradient nylon lenses are precision dip-dyed and quality-controlled — from blank forming through dual-zone tint verification.
International Quality Standards
Active certifications — verified & compliant
