Nylon Sunglasses Lens Solid Color Orange Tinted
Engineered Optical Excellence
Every lens inherits five core performance pillars — from optical purity to impact safety.
Supreme Optical Clarity
Engineered exclusively as 0.00D Plano Lenses with an Abbe Value of 52, rivaling crown glass for ultimate optical purity. Eliminates optical distortion, color fringing, and the "rainbow effect" typically associated with high base-curve lenses, ensuring racing-grade clarity.
Dip-Dyeing Tint Technology
Utilizing Precision Dip-Tinting, optical nylon demonstrates an exceptional affinity for premium dyes. This guarantees deep, uniform color integration—completely avoiding the muddiness of injection masterbatches—while maintaining strict batch-to-batch consistency with a Delta E < 1.0 and zero color migration.
Ultra-Lightweight & Crack Resistant
Boasting an ultra-low Density of 1.01 g/cm³ (16% lighter than PC). It exhibits outstanding mechanical stability and crack resistance, completely eliminating edge chipping risks during CNC drilling and slotting for rimless designs.
UV400 Full Protection
Delivers uncompromised safety through strictly controlled material properties, offering 100% blockage of harmful UVA and UVB rays (≤400nm, ≥99% blocking) across the full optical spectrum.
FDA Standard Impact Safety
Fully compliant with the FDA 21 CFR 801.410 drop-ball test, ensuring reliable mechanical safety for daily and fashion use within an ultra-thin 1.5mm profile.
Nylon Sunglasses Lens Solid Color Orange Tinted
Click to play and see the performance and details of our orange nylon lenses in real-world settings.
Technical Specifications
| Material | Optical Grade Nylon (Polyamide) |
| Color | Couture Orange (Pantone matching available) |
| VLT / Category | 18-43% / CAT 0, 1, 2, 3, 4 |
| UV Protection | UV400 (≤400nm, ≥99% blocking) |
| Abbe Value | 52 |
| Specific Gravity | 1.01 g/cm³ |
| Optical Accuracy | Plano 0.00D; Residual Astigmatism ≤0.09D; Residual Prism ≤0.12Δ, measured at the optical reference point. |
| Base Curve | 0.5C, 2C, 3C, 4C, 4.5C, 5C, 6C, 8C Available |
| Center Thickness | 1.2mm - 4.0mm (±0.05mm) |
| Diameter | 71mm / 75mm / 80mm (custom available) |
| Impact Test | FDA 21 CFR 801.410 Pass |
| Certifications | CE / FDA / UKCA / GB / ANSI / EN / AS/NZS |
| MOQ | 300 Pairs/Specification |
| Origin | Shenzhen, China |
| Logo | Laser engraving with oil, Screen printing, UV printing, Decal, Embedded logo |
Production-Ready Integration
Everything you need to source with confidence
- Acetate Frames — Highly recommended. Excellent chemical resistance against acetate plasticizers. Fully immune to stress cracking caused by cooling shrinkage during fitting
- Rimless / Drill-mount — Superior tensile strength ensures zero edge chipping during CNC drilling and slotting.
- Titanium / Carbon Fiber / Metal / TR90 Frames — Optimal compatibility, lightweight and corrosion-resistant, ideal for premium eyewear frame designs.
- Pantone matching for precise solid base colors
- Standard UV protection integrated in all lenses
- B-AR (Back-Surface AR) coating recommended to eliminate rear reflections
- Coating upgrades: HC / Oleophobic / Hydrophobic / Anti fog
- Simple Packaging: PE bag + white box, Premium Packaging: Individual color box + cloth bag, Blister: Transparent blister box, Custom: Brand LOGO packaging
- MOQ: 300 Pairs/Specification
- Sample Lead Time: 7–10 working days, allowing you to verify quality before bulk order
- Bulk Lead Time: 15–20 working days (subject to quantity and customization complexity)
- Custom Options: Pantone color matching, B-AR coating
- Reports: Light Transmittance Test Report, UV Blocking Test Report, Impact Resistance Test Report, Color Consistency (Delta E) Test Report, Salt Spray Test Report
Features & Applications
Lens Category
| Category | VLT (%) | Usage Environment |
|---|---|---|
| CAT 0 | 80% - 100% | Indoor or overcast low-light conditions |
| CAT 1 | 43% - 80% | Low-light outdoor, overcast |
| CAT 2 | 18% - 43% | Medium light, daily outdoor |
| CAT 3 | 8% - 18% | Strong outdoor light, sunny |
| CAT 4 | 3% - 8% | Extreme light, e.g., skiing, mountaineering |
Technical Features
- Optical Purity: An Abbe Value of 52 puts this nylon (PA-12) lens on par with crown glass for clarity—customer complaints about distortion and color fringing are essentially eliminated before they reach your after-sales team.
- Precision Tint Control: Wide VLT coverage (18–43% / CAT 0–4) is locked in through precision dip-dyeing, with strict Delta E < 1.0 batch-to-batch color consistency. Rejected shipments due to hue mismatches become a non-issue for your production line.
- UV400 Compliance: 100% blockage of UVA and UVB rays (≤400nm, ≥99% blocking) is guaranteed across every unit. This full-spectrum compliance satisfies CE, FDA, ANSI, and AS/NZS requirements simultaneously, clearing the way for global market entry without separate regulatory rework.
- Scrap Reduction: At 1.01 g/cm³—16% lighter than PC—this lens delivers the mechanical stability required to virtually eliminate edge chipping during CNC drilling and slotting. Rimless and drill-mount assembly yield rates improve directly.
- Mechanical Safety: The FDA 21 CFR 801.410 drop-ball standard is fully met within a 1.5mm center thickness. For Premium Eyewear Brands and E-commerce D2C Brands, this compliance floor protects both end consumers and your returns rate.
- Scalable Customization: Available across base curves 0.5C–8C, center thicknesses 1.2mm–4.0mm (±0.05mm), and diameters up to 80mm, with Pantone color matching and B-AR coating options. New colorways can be prototyped starting at 300 pairs per specification.
Perfect For
- Premium Eyewear Brands
- Independent Eyewear Designers
- Private Label Distributors
- E-commerce D2C Brands
- Sports & Automotive Lifestyle Labels
- Department Store Groups
Overview
Orange-tinted lenses occupy a precise position in the eyewear palette — high visual warmth, contrast-enhancing character, and light transmission flexible enough to carry a collection from fashion-forward casual to mid-light outdoor use.
Dip-dyed color that holds within strict batch-to-batch tolerances means the shade your designer approves is the one your customer unboxes — your retail line runs without the QA stops that erode production schedules. When a collection calls for its own color story, Pantone-matched tints and tailored coating stacks can be specified in your brief; your design language carries from concept to finished sample, built in-house at Xinxin.
